LEDPROFILE LARGE MONOCHROME IP20 12VDC

Download datasheet

SPECIFICATIONS

SMD LED(S) 360 per meter
MAX. POWER 29 Watt 2,41Amp per meter
BEAM ANGLE 120°
CRI 90+
VOLTAGE 12 VDC
GEAR / DRIVER Not included
MATERIAL Aluminium / Pmma
MAX. LENGTH 50/6000 mm
WEIGHT (KG) 1,4
IP 20
ORDER PER METER
OPTIONS: Possible options see Accessories. Excludes power cable (order separately). Dimmable (cfr. Accessories)
249,90 €

Contact Us

MODELS

Article n° Description Colour Kelvin Lumen LDT
020011112702 LEDPROFILE SMALL INT. WARM WHITE BLACK STRUC. 2700 2200
020011113002 LEDPROFILE SMALL INT. WARM WHITE BLACK STRUC. 3000 2400
020011114002 LEDPROFILE SMALL INT. NATURAL WHITE BLACK STRUC. 4000 2640
020011116002 LEDPROFILE LARGE INT. WARM WHITE BLACK STRUC. 6000 3000
020011112701 LEDPROFILE SMALL INT. WARM WHITE WHITE STRUC. 2700 2200
020011113001 LEDPROFILE SMALL INT. WARM WHITE WHITE STRUC. 3000 2400
020011114001 LEDPROFILE SMALL INT. NATURAL WHITE WHITE STRUC. 4000 2640
020011116001 LEDPROFILE LARGE INT. WARM WHITE WHITE STRUC. 6000 3000
020011112716 LEDPROFILE SMALL INT. WARM WHITE NATURAL ANODIZED 2700 2200
020011113016 LEDPROFILE SMALL INT. WARM WHITE NATURAL ANODIZED 3000 2400
020011114016 LEDPROFILE SMALL INT. NATURAL WHITE NATURAL ANODIZED 4000 2640
020011116016 LEDPROFILE LARGE INT. WARM WHITE NATURAL ANODIZED 6000 3000
020011112703 LEDPROFILE SMALL INT. WARM WHITE ANY RAL 2700 2200
020011113003 LEDPROFILE SMALL INT. WARM WHITE ANY RAL 3000 2400
020011114003 LEDPROFILE SMALL INT. NATURAL WHITE ANY RAL 4000 2640
020011116003 LEDPROFILE LARGE INT. WARM WHITE ANY RAL 6000 3000
COLOR WHITE STRUC. or BLACK STRUC. or ANY RAL or NATURAL ANODIZED
LUMEN OUTPUT 2700 or 3000 or 4000 or 6000
MOUNTING SURFACE or RECESSED or SUSPENSION
FIXATION CEILING or WALL
APPLICATION HOME INTERIOR
