EDJA FLAT IP20 24VDC 14,4W

Download datasheet

SPECIFICATIONS

SMD LED(S) 360 per meter
MAX. POWER 28,8 Watt 1,2Amp per meter
BEAM ANGLE 120°
CRI 90+(opal) 75+(Black)
VOLTAGE 24 VDC
GEAR / DRIVER Not included
MATERIAL Aluminium / Pc
MAX. LENGTH 50/6000 mm (1 profile/ 1 defuser)
WEIGHT (KG) 1,7
IP 20
ORDER PER METER
OPTIONS: INTERNAL DRIVER = ORDER SEPARATELY : LINJA POWER SUPPLY 24VDC 20W P/M ORDER CODE : 800241070036
227,00 €

Contact Us

MODELS

Article n° Description Colour Kelvin Lumen LDT
048281112209 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING BLACK STRUC. 2200 1400 -
048281122209 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 2200 1400 -
048281112709 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING BLACK STRUC. 2700 1400 -
048281122709 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 2700 1400 -
048281113009 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING BLACK STRUC. 3000 1600 -
048281123009 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 3000 1600 -
048281114009 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - BAKCPLATE MOUNTING BLACK STRUC. 4000 1800 -
048281124009 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 4000 1800 -
048281112210 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING BLACK STRUC. 2200 1120 -
048281122210 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 2200 1120 -
048281112710 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING BLACK STRUC. 2700 1120 -
048281122710 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 2700 1120 -
048281113010 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING BLACK STRUC. 3000 1280 -
048281123010 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 3000 1280 -
048281114010 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - BAKCPLATE MOUNTING BLACK STRUC. 4000 1440 -
048281124010 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 4000 1440 -
048281112206 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING WHITE STRUC. 2200 1400 -
048281122206 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 2200 1400 -
048281112706 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING WHITE STRUC. 2700 1400 -
048281122706 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 2700 1400 -
048281113006 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING WHITE STRUC. 3000 1600 -
048281123006 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 3000 1600 -
048281114006 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - BAKCPLATE MOUNTING WHITE STRUC. 4000 1800 -
048281124006 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 4000 1800 -
048281112207 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - BACKPLATE MOUNTING WHITE STRUC. 2200 1120 -
048281122207 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 2200 1120 -
048281112707 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING WHITE STRUC. 2700 1120 -
048281122707 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 2700 1120 -
048281113007 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING WHITE STRUC. 3000 1280 -
048281123007 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 3000 1280 -
048281114007 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - BAKCPLATE MOUNTING WHITE STRUC. 4000 1440 -
048281124007 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 4000 1440 -
048281112228 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING NATURAL ANODIZED 2200 1400 -
048281122228 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 2200 1120 -
048281112728 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING NATURAL ANODIZED 2700 1400 -
048281122728 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 2700 1400 -
048281113028 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING NATURAL ANODIZED 3000 1600 -
048281123028 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 3000 1600 -
048281114028 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING NATURAL ANODIZED 4000 1800 -
048281124028 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 4000 1800 -
048281112229 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING NATURAL ANODIZED 2200 1120 -
048281122229 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 2200 1120 -
048281112729 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING NATURAL ANODIZED 2700 1120 -
048281122729 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 2700 1120 -
048281113029 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING NATURAL ANODIZED 3000 1280 -
048281123029 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 3000 1280 -
048281114029 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - BACKPLATE MOUNTING NATURAL ANODIZED 4000 1440 -
048281124029 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 4000 1440 -
048281112212 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING ANY RAL 2200 1400 -
048281122212 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 2200 1400 -
048281112712 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BACKPLATE MOUNTING ANY RAL 2700 1400 -
048281122712 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 2700 1400 -
048281113012 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - BAKCPLATE MOUNTING ANY RAL 3000 1600 -
048281123012 LEDPROFILE EDJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 3000 1600 -
048281114012 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - BAKCPLATE MOUNTING ANY RAL 4000 1800 -
048281124012 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 4000 1800 -
048281112213 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BAKCPLATE MOUNTING ANY RAL 2200 1120 -
048281122213 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 2200 1120 -
048281112713 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - BACKPLATE MOUNTING ANY RAL 2700 1120 -
048281122713 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 2700 1120 -
048281113013 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 3000 1280 -
048281123013 LEDPROFILE EDJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 3000 1280 -
048281114013 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - BACKPLATE MOUNTING ANY RAL 4000 1440 -
048281124013 LEDPROFILE EDJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 4000 1440 -
COLOR WHITE STRUC. or BLACK STRUC. or ANY RAL or NATURAL ANODIZED
KELVIN 2200 or 2700 or 3000 or 4000
TO MOUNT MAGNET or BACKPLATE
DIFFUSOR PC FLAT OPAL or PC FLAT BLACK
MOUNTING SURFACE or RECESSED
FIXATION CEILING or WALL
APPLICATION HOME INTERIOR
WATT 28,8
